Lower Gear Unit: 854050 DRIVE DP-A

1 2 3 4 5 6 7 8 9 10 11 12 13 14 14 15 16 17 18 18 18 18 19 20 21 22 23 24 25 25A 26 26A 27 28 28 28 28 28 29 30 30 30 31 32 33 33 34 35 36 37 38 38 38A 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53

#	Наименование	Код
1	Lower gear	854050
2	Housing	854051
3	Bearing housing	3857097
4	Attaching plate	852643
5	Blind rivet	948338
6	Check valve	852644
7	Fin	854054
8	Fin	854054
9	Countershaft	852183
10	Needle roller bushin	184654
11	Inner ring	184682
12	Drive gear set	852380
13	Nut	852212
14	Shim	941832
14	Shim	941833
15	Ball bearing	183374
16	Shim	944970
17	Roller bearing	11072
18	Shim	968057
18	Shim	944522
18	Shim	42981
18	Shim	42980
19	Tensioning ring	897387
20	Lock washer	907023
21	Round nut	906633
22	Oil strainer	814482
23	Magnetic plug	852904
24	O-ring	955974
25	Propeller shaft	852181
25A	Roller bearing	11044
26	Roller bearing, compl.	184765
26A	Inner ring	184690
27	Cup	184689
28	Shim	967351
28	Shim	941823
28	Shim	943252
28	Shim	941824
28	Shim	941825
29	Roller bearing	184691
30	Shim	81376
30	Shim	81375
30	Shim	81374
31	O-ring	925258
32	Hex. socket screw	941812
33	zinc ring	0001871607
33	Zinc ring kit	875821
34	Screw	966808
35	Needle roller bushin	183859
36	Inner ring	184683
37	Sealing ring	851407
38	Line cutter	853440
38	Plastic washer	854294
38A	Plastic washer	853584
39	Needle roller bearin	183272
40	Sealing ring	853871
41	Lock washer	853869
42	Propeller nut	852196
43	Line cutter	853441
44	Propeller cone kit	854243
45	propeller cone	0001871621
46	Washer	941670
47	Hexagon screw	852216
48	O-ring	925256
49	Splined sleeve	850304
50	Washer	853095
51	Hex. socket screw	941810
52	Anode kit	876138
53	Screw	966808
