| # | Наименование | Код | |
| 1 | Carburetor | 841352 | |
| 2 | housing | 0003130678 | |
| 3 | Float | 831824 | |
| 4 | Float spindle | 831877 | |
| 5 | Air outlet | 841788 | |
| 6 | Fitting | 824758 | |
| 7 | Screw | 824759 | |
| 8 | Nozzle | 841790 | |
| 9 | gasket | 0003130685 | |
| 10 | screw | 0003130686 | |
| 11 | Idle jet | 841789 | |
| 12 | Main jet | 824763 | |
| 13 | Retainer | 824764 | |
| 14 | gasket | 0003130690 | |
| 15 | Accelerator pump | 841551 | |
| 16 | cover | 0003130692 | |
| 17 | diaphragm | 0003130693 | |
| 18 | spring | 0003130694 | |
| 19 | Screw | 824761 | |
| 20 | Shutter housing | 834561 | |
| 21 | shaft | 0003130697 | |
| 22 | throttle disc | 0003130698 | |
| 23 | screw | 0003130699 | |
| 24 | Adjusting screw | 824780 | |
| 25 | Spring | 824779 | |
| 26 | Adjusting screw | 824778 | |
| 27 | adjusting lever | 0003130703 | |
| 28 | Hexagon screw | 955270 | |
| 28 | Screw | 824783 | |
| 29 | Spring washer | 824784 | |
| 29 | Spring washer | 941905 | |
| 30 | fork | 0003130708 | |
| 31 | washer | 0003130709 | |
| 32 | nut | 0003130710 | |
| 33 | gasket | 0003130711 | |
| 34 | sleeve | 0003130712 | |
| 35 | spring | 0003130713 | |
| 36 | lever | 0003130714 | |
| 37 | Check valve | 824817 | |
| 38 | Strainer | 824785 | |
| 39 | gasket | 0003130717 | |
| 40 | Push rod | 841552 | |
| 41 | Cardboard tube | 841550 | |
| 42 | Needle valve | 834662 | |
| 43 | gasket | 0003130721 | |
| 44 | gasket | 0003130722 | |
| 45 | Screw | 824795 | |
| 46 | Lock washer | 824796 | |
| 47 | Hexagon screw | 955270 | |
| 48 | Spring washer | 941905 | |
| 49 | Repair kit | 841292 | |
| 49 | Gasket kit | 824803 | |
| 49 | Washer | 955892 |
